ATS offers a complete range of automotive testing services from chemical to mechanical and environmental testing. We perform the following methods of Volkswagen SAE standards testing to ensure that parts and materials are consistent with industry standards, government regulations, and consumer expectations.
Reference Specs | Tests |
---|---|
(DIN 53479) DIN EN ISO 1183-1 | Density |
ISO 11357 / DSC Method (Substituted for ISO 3146) | Melting Temperature |
DIN EN ISO 1133-A, Code T | Melt Mass-Flow Rate |
DIN EN ISO 1172 | Ignition Residue |
DIN EN ISO 527-1 | Breaking Stress |
DIN EN ISO 527-2 | Yield Stress / Tensile Strength |
DIN EN ISO 178 | Flexural Strength |
DIN EN ISO 178 | a. Modulus of Elasticity — Room temperature b. Modulus of Elasticity — High temperature c. Modulus of Elasticity — Low Temperature |
DIN EN ISO 179-1/1eU; DIN EN ISO 179-1 | Un-Notched Impact Strength / (Charpy) Impact Resistance |
DIN EN ISO 179-1/1eA; DIN EN ISO 179-1 | Notched Impact Strength / Charpy Impact Resistance |
DIN EN ISO 306 / A50 or B50 | Vicat Softening Temperature/ Dimensional Stability |
ASTM E1252-98 (2013) | Material FTIR |
DIN 53497 | Elevated Temperature Behavior |
DIN 53491 | Elevated Temperature Behavior |
DIN 53497 | Low Temperature Behavior |
PV 3905 | Ball Drop Test |
PV 3929 | Kalahari Test |
PV 3930 | Florida Test |
Resistance to Aging | |
Resistance to Agents | |
TL211 | Paint Coating |
TL226 | Thermal Conditioning |
PV 3925 | Formaldehyde Emissions |
PV 3341 | Emission of Organic Compounds / Total Emissions / VOC |
VW 50180 | Emission of Organic Compounds / Total Emissions / VOC |
PV 3015 | Condensable Constituents / Emission Behavior (Fogging) |
PV 3900 | Odor |
PV 1303 | Lightfastness / Colorfastness / High Temperature Light Exposure |
PV 1306 | Tackiness |
PV 1200 | Environmental Cycle |
PV 2005 | Environmental Cycle |
Initial Condition per DIN EN ISO 2409 | Cross-Cut Adhesion |
Aging at Elevated Temperature | |
DIN EN ISO 6270-2 | Condensed Water Constant Climate |
Corrosion Cycle | |
Scribe | |
PV 3906 | Abrasion: – 100 Crockmeter Strokes w/Dry Cloth – 100 Crockmeter Strokes w/Moist Cloth – 2000 Crockmeter Strokes w/Dry Cloth per |
Resistance to Agents — Drop Test | |
Abrasion Behavior — Cleaning Agents | |
PV 3964 | Cream Resistance |
TL 1010 | Burning Behavior / Flammability |
VW 50190 | Colorimetric Evaluation |
Environmental Aging | |
Heat Aging | |
PV 3904 | Low Temperature Aging |
PV 3937 | Amine Behavior |
Resistance to Cleaning Agents | |
Cleaning Behavior | |
Bonding | |
Low Temperature Behavior | |
Elevated Temperature Behavior | |
PV 3966 | Stress Whitening |
Section 5.6 | Low Temperature Behavior |
Color Analysis | |
Heat Aging | |
PV 2034 | Adhesion of Decorated Material |
DIN EN ISO 1172 | Glass Fiber Content |
Section 3.2 | Moisture Content |
DIN EN ISO 2039-1 | Ball Indention Hardness |
DIN EN ISO 307 | Viscosity Number |
Aging Resistance | |
DIN 53505 | Hardness Test (Shore D) |
DIN EN ISO 1172 | Mineral Content |
