The Applied Technical Services Family of Companies (ATS FoC) is a leader among concrete X-ray companies. Concrete is revered for its strength, durability, and cost-effectiveness, and is widely used in commercial and residential construction. Before modifying or renovating concrete structures and surfaces, it’s important to determine what objects lie beneath the concrete. Our concrete X-ray scans generate images of the interior of concrete structures, helping to map out objects before renovations and modifications occur.
What is Concrete X-Ray Scanning?
Concrete X-ray scanning uses X-rays to create detailed images of the conditions and objects beneath a concrete structure or surface. During scanning, technicians place a radiation source on one side of a concrete structure and a detector film on the other. Once the radiation passes through the concrete, technicians interpret the image and learn more about the concrete’s interior structure. This process helps technicians identify the presence and location of various objects that may be hidden beneath the concrete, such as:
- Rebar
- Conduits
- Pipes
- Embedded water or gas lines
Concrete X-ray scanning reveals the exact size, location, and orientation of these objects, minimizing the risk of construction teams accidentally damaging critical equipment. Scans can also help detect the presence of various anomalies in a concrete material, including:
- Honeycombing
- Cracks
- Voids
About Our Concrete X-Ray Scanning Services
Our highly trained nondestructive testing (NDT) experts provide concrete radiography services that determine the subsurface conditions of concrete materials, structures, and surfaces. We deploy X‑ray scanning systems across a wide array of job sites to locate objects and anomalies present in concrete. Upon completing our scans, our team members analyze and interpret images to support contractors’ cutting, drilling, and coring objectives.
Why Concrete Scanning Matters
Concrete scanning prevents accidental damage to structural elements and utilities, which can lead to expensive repairs, project delays, and hazardous conditions. This also helps contractors make informed decisions about where to cut or core and whether additional structural evaluation is needed.
Contact Us
Call +1 (888)-287-5227 or submit an online request form to speak with one of our team members about Concrete X-ray scanning services.
