Applied Technical Services now offers in-house seismic vibration testing in full compliance with the requirements of IEEE 344. Our experts can tailor testing procedures to client specifications, GR-63-CORE, AC-156, and IBC Standards.

Seismic Vibration Testing Capabilities

  • 3 Independent Simultaneous Axes of Motion (X,Y,Z translation)
  • Table Size of 36″x36″ with Grid of 1/2″ – 13 Tapped Holes on 4″x4″ Pattern
  • Actuators Rated at 10,000 lbf
  • Peak Displacement of 12 Inches P-P (+/-6″)
  • Rated Velocity of 52 IPS
  • Frequency Range of Operation 0-100 Hz with Ability to Operate Up to 150 Hz for Purposes of Resonance Searches
  • State of the Art PC-Based Digital Controller (Vibration Research) and 12 Channels of Piezoelectric Accelerometers
  • Independent High-Speed DAQ Systems for Chatter Monitoring (64 Channels)

Quality Standards

  • ASME NQA-1 Nuclear Quality Assurance Requirements
  • 10 CFR 50 Appendix B Nuclear Quality Assurance Requirements
  • 10 CFR 21 Requirements for the Reporting of Non Conformances
  • ISO/IEC 17025 Competence of Testing and Calibration Laboratories
  • ISO 9001:2015 Quality Management System
  • NCSL Z540-1 Calibration System Requirements

High-Quality Testing Services

Applied Technical Services is a leader in inspections, testing, and consulting engineering. We maintain a reputation of excellence in customer service by prioritizing our clientsโ€™ needs. Our customer service ambassadors connect clients directly to relevant, knowledgeable experts who can help find solutions to their problems. Our experts deliver clear, precise data as quickly as possible and remain available to clients who have any additional inquiries.

If you need seismic testing services, contact ATS today. We take a closer look!
