Most metals have electrical resistance, which is affected by their purity. If electrical resistance is higher or lower than expected, it can cause equipment damage, poor product performance, or hazardous conditions that result in injury. Measuring electrical resistivity or conductivity with a handheld multimeter seems straightforward, but this method proves less accurate when the values are very high or low. While a handheld multimeter is useful for testing circuit continuity, other techniques are more accurate and more reliable for reading conductivity.
ASTM B193 Testing
The ASTM B193 standard tests metallic electrical conductor materials for conductivity and resistivity. The test is recommended on samples with a resistance of 0.00001 ohms (or 10 microohms) and above. Temperature affects a metal’s electrical resistance, a consideration for which ASTM B193 accounts. Inaccuracies in the conductor’s assumed density may affect the accuracy of weight resistivity values, however.
ATS’ Electrical Testing Lab
We equip our ISO 9001:2015 registered labs with advanced technology, allowing us to take accurate readings. Our electrical testing experts are familiar with current test methods and compliance regulations. We adhere to several testing standards, including ANSI, IEC, ASTM, MIL-STD, and IEEE. Testing applications include:
- Dielectric Constant
- Insulation Resistance
- Surface and Volume Resistivity
- Contact Resistance
- Dielectric Strength
- Voltage Drop Testing
- Conductivity
Certified Quality Assurance
Founded in 1967, Applies Technical Services is a leader in consulting engineering, with extensive inspection and testing capabilities. We serve many industries:
- Aviation
- Consumer Products
- Manufacturing
- Nuclear
- Plastics and Polymers
- Automotive
- Chemical
- Power Generation
- Power Transmission
- Railroad
- Military
- Energy
- Telecommunications
- Solar
- Oil and Gas
ATS is ISO 9001:2015 registered, with ISO/IEC 17025 (A2LA) accreditations to perform in mechanical, NDT, and chemical testing standards, as well as an array of calibration services. We prioritize customer satisfaction, which is why we offer accurate testing, detailed reporting, competitive pricing, and quick turnarounds. Our customer service ambassadors connect clients with experienced technicians and specialists who can answer their questions regarding test data and results. We measure our success by the satisfaction of our clients, so they can trust that ATS is the right decision when it comes to testing, inspections, and engineering consulting.
If your company needs conductivity ASTM B193 testing, contact Applied Technical Services.
